Sunday, July 13, 2014
Answers to Questions 1 - Juno 106 Module Board Test Points
Published on Jul 13, 2014 Syntegrator
"I was asked via private message a question concerning early model Juno-106 module boards - These are missing test points 14-19 as shown in my calibration videos. This video covers the specifics of the early revision module board and explains how to find the equivalent test points on the appropriate trimmer controls."
