Wednesday, August 17, 2016

New CEM3340 VCO Eurorack Module Coming from nonlinearcircuits


via nonlinearcircuits

"I generally prefer to use generic components for new designs, but couldn't resist making a module for the newly re-released CEM3340 VCO IC.

This is very much based on the Aries AR-338 PMS VCO, which features phase modulated sync and a pan-pulse output. The AR-338 used a SSM2030, so it was not too hard to modify the sub-sections to suit the CEM3340. As you can see, for such a feature rich VCO, there are not all that many components."


The back of the panel.
