via Innerclock"Inputs
Clock Input – TRS 1/4″ [Sync-Gen II DAW Audio]
Transport Input – TRS 1/4″ [Sync-Gen II DAW Audio]
Gate Input – [+5VDC - Normalled High]
Outputs
Reset Output – [20ms/+5VDC]
Simultaneous Trigger Output Divisions – 1/2/2T/4/4T/8/8T/16 [20ms/+5VDC]
Midi Clock Output – 24 PPQ with Programmable Re-Start, Division Rate and Swing via Sync-Gen II software
Din Sync Output - 24 PPQ with Programmable Re-Start, Division Rate and Swing via Sync-Gen II software
Features
Sample Accurate Rhythmic Synchronization between any DAW and any Modular Synthesizer system
Zero Latency with Precision Sync-Offset adjust via Sync-Gen II
Works with any multi-channel DAW audio interface – no DC Offset hardware or cable modification required
Includes Sync-Gen II software – AU/VST/RTAS
Simultaneous Phase-Locked Outputs – Midi Clock/Din Sync and All Trigger Out Divisions
20 microsecond Pulse Edge Detection/Sync Conversion Timing Core
External Analogue Gate Input allows ‘playable’ output pulses while maintaining precise DAW Tempo-Grid synchronisation
Electrical Specifications
Clock Input Impedance – 10k
Clock Input Threshold Range – 350mV to 1.40V [500mV Optimum]
Transport Input Impedance – 10k
Transport Input Threshold Range – 350mV to 1.40V [500mV Optimum]
Trigger Outputs – +5VDC/20ms Pulse Width * Power – +/-12V or +/-15V or +/-9V [Eurorack and Frac sockets fitted]
Mechanical Specifications
Format – Eurorack
Note: Picture shown is Rev1 Prototype - Production scheduled for December 2011"
