MATRIXSYNTH: Saturday, August 8, 2015

Saturday, August 08, 2015

ALM Dinky's Taiko - cyrusrex

ALM Dinky's Taiko - cyrusrex from Muff Wiggler on Vimeo.

Follow-up to cyrusrex / LS019

"Patch by cyrusrex of MW Store.

Recording Using only the Dinky's Taiko as a Main Source.
Clock from 4MS QCD to RCD.
Channel 1 of QCD is sent to RCD and is being modulated by Pressure Points thru a SISM, It Is also triggering Dinky.
Channel 2 of QCD is routed to Xaoc Moskwa Sequencer 1, which is modulating Pressure Points Play Direction and Run/Stop.
RCD div2 is headed to Moskwa 2 Sequencer, which is modulating ErbeVerb Mix Amount (via SISM fine tuning). It is also going into a OptoMix to gate the modulation to only occur at certain times which is modulating Dinky's End Freq Control and Noise Control Input.
Channel 3 of QCD is controlling tempo of the FX Modules used. ErbeVerb and Echophone.
Channel 4 of QCD is controlling Brain's Tempo.
Multiple Pressure Points and Analog Memory Channels are Controlling Dinky's Wave, OSC Release, Noise Release, Spectrum, Mix. This is the root of the patch as it gives the variation to the drum sounds.

Dinky's output heads to a Malekko Mult, then gets split to the main routes:
Copy 1 goes Direct Out
Copy 2 goes to The Echophone, then to a MMG. MMG filter is modulated by Pressure Points and a 4MS QPLFO. Echophone's Mix, and Feedback Control modulated by Pressure Points.
Copy 3 goes to ErbeVerb which is having its Decay Control and Mix modulated by Pressure Points.
Copy 4 is from another of ErbeVerbs's outputs through BL Mr Blue's Wave-folder section then to a WMD Compressor. Compressor Side-chain is being used with the Original Dinky Sound. This gives some distorted Sounds which further get processed an Eventide Space ten cwejman compressor, then into a Macbeth BackEnd Filter which has its cut-off being swept by a Cwejman Envelope triggered by Moskwa 1's Gate Output in random mode."



via the seller:

"Selling my loaded Sequentix Cirklon, serial 094. It has the CVIO board, rack mount CVIO break out box, rack ears, original hard cover manual and power supply. In addition to this I am throwing in the v1.0 D-MUX eurorack module. This will allow your Cirklon to sequence a full 16 additional drum triggers and accents when connected to the DIN Sync output on the device! The price covers shipping worldwide!"

1976.3 Roland Electronic Musical Instrument Japanese Catalog

via this auction

"Roland Electronic Musical Instrument Catalogue Japanese !! (18p)



◆It is really a read used old VINTAGE Catalog some damage,(fold,fade,tears,stains),please be understood bid it.

vintage used condition:-)
(Please L@@K See Photo!)

Thanks so much!!"

1978 Vol.3 Roland Electronic Musical Instrument Catalog

via this auction

Dual Modular Jam 02

Published on Aug 8, 2015 Zeropage

"2 Euroracks with the DrumDokta2 (Dr Rhythm DR-110 Clone) and a TB-3"

cyrusrex / LS019

cyrusrex / LS019 from Muff Wiggler on Vimeo.

"Recorded Live July 28, 2015. All Source is Multi-tracked Modular Synth, later mixed in Pro Tools HDx. Additional Processing with Eventide H8000 + Strymon Big-Sky."

Moog Sonic6 - Q960 - some more sequencing....

Published on Aug 8, 2015 noddyspuncture

"You'll need headphones or some good speakers to hear all of this. Laptop speakers just won't give you the full bottom end where a lot of this is happening...! Moog Sonic6 "played" via a Q960 sequencer... you can't beat it...;)"

Twisted Electrons Acid 8 Jams

Acid 8 Twisted Electrons (Jam 1) & PO-12 Published on Aug 8, 2015 space travel made easy

"Little jam with Twisted Electrons Acid 8 and Teenage Engineering PO-12 Drum Machine. Just programmed both really quickly for a jam to show the kind of sounds the Acid 8 can come up with.

This is by no means a finished song and just touches on what the little Acid 8 is capable of. I cannot recommend this little Acid machine enough. You need one in your life. Such fun just to jam with, patterns etc can easily be copied and pasted on the fly as you jam."

Acid 8 Twisted Electrons (Jam 2) & Korg Volca Sample

Acid 8 Twisted Electrons (Jam3) & PO-12

Egyptian Lover Builds a Beat Live on the Roland 808 | 1983 - 2012

How to use a Roland TR-808 Rhythm Composer by The Egyptian Lover 1983

Published on Jul 30, 2012 flashmanboogie

Three vids of the Egyptian Lover and the TR-808 on 808 day!

"The Egyptian Lover demonstrates the Roland TR - 808 Drum Machine
("TR" initialism for Transistor Rhythm)
Breakin' n' Enterin' (U.S.-TV Cutscene 1983)"

Published on Sep 25, 2012 FACTmagazine

"So a while ago, we linked to a video that you all seemed to like very much.

It was from the extended TV version of 1983 documentary Breakin' n Enterin', and featured Egyptian Lover, one of the masters of the Roland-TR808 drum machine, giving a brief tutorial on how to use the box (filmed, we believe, around 1981). You can watch it here: [embed above]

Now, given how popular FunkinEven's recent MPC tutorial for FACT TV also was, when we heard that the Egyptian Lover was in London this Summer, we asked if he was down to recreate the scene for 2012. Being a total gent, he was up for it, and built a beat live for us in his hotel room after performing at Blunted. Of course the speakers that we brought didn't work, so the Lover ended up plugging his 808 straight into the hotel alarm clock, which made it all even cooler.

Filmed by Kamil Dymek"

And one of the classic tracks that made everyone love the 808:

The Egyptian Lover - Egypt, Egypt

Uploaded on Feb 26, 2008

"One of 1984's finest. Born Greg Broussard, The Egyptian Lover started off doing his thing as a Los Angeles DJ doing parties at the LA Sports Arena, and later putting his stamp on the hip-hop/electro scene with this memorable song that I still play to this day!!!! You can see this brother performing and coming to a town near you. Man, I feel like breakdancing right damn now, but my arthritis won't let me LOL"

AJH Synth MiniMod - VCO

Published on Aug 8, 2015 DivKidMusic

"Here's the oscillator from the AJH Synth MiniMod voice which is truly one of the best synths I've heard (modular or otherwise). Not something I take to saying lightly as I'm not one to announce something big like that but really it's awesome!

I've tried to demo how the raw character of the oscillators are while showing how these go much further than the Minimoog Model D that the circuits are modelling.

I'll have videos of every module in the MiniMod series as well as system overviews looking at the voice as a whole.

As always hit like and subscribe for more videos every week and check the Patreon link in the description to see how you can support my channel."

Shibuya demo of PCB prototype

Published on Aug 8, 2015 RazmatazTG

"Demo of Razmasynth prototype module's named Shibuya:
LFO with 9 waveforms, Clock out, Clock divider out, clock Multiplier out, , Start/Stop button, pulse canon to trig 2x 8 stps sequencer as an 16 steps seq and a RGB Led control for illuminating your rack to the rhythm of the LFO, or any waveform you patch in!
Coming September end 2015, with acryl rack earside and RGB led ribbon 1 to 5 meter."

'60s Korg Donca Matic Mini Pops 5 ~Analog Drum Machine Synth~ Keio Electronic SN 723676

via this auction

"This auction is Keio Electronics Lab (Korg) Mini Pops 5 analog drum machine. This unit was built by Keio Electronics Lab, which was the original name for Korg! This machine was originally designed to attached to your favorite organ where it could then be connected up to a speaker and set to accompany your playing with only a touch of the "magic" metal bar on the front of the unit! Today, these are very popular for "circuit benders" and other modification to create very cool drum machines!

This unit is unfortunately untested due to the lack of the power cord and the fact that I don't want to ruin one of these very, very rare units! The unit is in great physical condition though, having only minor scratches and dust..."

Concertmate MG-1 Moog Vintage Analog Synthesizer SN 5634

via this auction

"Synth works perfectly. Fully calibrated.

Cosmetically its in good shape. There are a few minor scrapes on the rear but nothing major.

The RCA jacks have been removed and replaced with 1/4" jacks. The output has also been modified for proper line level. The other jack is Audio In. The Gate In has been modified to accept standard gate signals, instead of the S-trig Moog standard.

All of the faders work but could benefit from being reconditioned. Some of the fader caps are missing the silver foil and 1 cap is missing.

There was a knob added to the left of the keyboard for PWM of VCO 1, but is fairly limited. There is also a jack that sends it to the LFO, but again this effect is fairly limited and I just never had the time to look into it further."

Moog Prodigy SN 1246

via this auction

"This Prodigy is in stunning mint condition. Most synths this old show signs of wear but this one looks like it was bought yesterday! All of the silk screening is intact. There are no visible scratches or scuffs.

This is one of the early Prodigy's that had some issues with tracking, but this one was professionally modified by Deltronics following Moog's official mod procedures. Both VCO's track perfectly!

The wood case is all original but I took it apart, sanded, stained and put on several coats of polyurethane."

Roland SH-09 Vintage Analog Synthesizer

via this auction

"All faders have been rebuilt (removed, disassembled, cleaned & lubed). VCO & Filter have been calibrated. Some minor signs of wear but nothing major. Both power LED & LFO LED have been changed from red to orange. There are 2 3.5mm jacks at the rear. One control the VCF Cutoff. I am unsure what the other does. There is a 3rd hole that was controlling the envelope but I removed it as it affected how the envelopes triggered from the selector switch on the front. Also, I internally wired the headphone Out to the Audio In jack's unused switch, so when nothing is plugged in it feeds the synth back into the filter causing some insane overdrive. When a jack is inserted it breaks this connection."

Modular Synth - Patch in Progress 14

Published on Aug 8, 2015 isvisible / isinvisible

Switches up at :45.

"Just working out a track. - melodic - less melodic"

Roland Celebrates 808 Day with $8.08 off Roland AIRA Merchandise

via Roland US


Celebrate 808 Day (August 8th) with big savings on all Roland AIRA merchandise. Enter promotion code 808day to receive $8.08 off your total purchase. Valid August 8–9, 2015 only."

Jupiter Clone - VCO Modulation and VFC LFO modulation controls

Published on Aug 8, 2015 tiergrinder

"Update 8/8/2015

VCO ENV/LFO and VFC LFO modulation circuits are now build and working. Calibration is still needed but everything works as it should.
VCO Mod control has switch similar to JP8 that chooses which VCO/VCOS are modulated, VCO1, VCO2 or Both.

Next I will start working on sync circuits."

SoundForce SFC-Mini - Mini-V/Monark - Minimoog-style MIDI controller

Published on Aug 8, 2015 SoundForce

"Check out the handmade prototype of my new Minimoog MIDI controller. It's compatible with the ARTURIA Mini-V as well as the NATIVE INSTRUMENTS Monark synth plugins. Please share this video if you like it and if you want to support my work."

YuSynth Wavefolder and Ian Fritz 5pulser demo

Published on Aug 8, 2015 vinnui

Update: some pics on vinnui's blog here.

"This is a short demo of the 2 waveshapers, controlled by 2 LFOs. Arp by Arturia Minibrute. All sounds are coming from the DIY modular.

Demo patch:

- VCO 1 is going into Yusynth/J.H Wavefolder, controlled by an LFO.
- VCO 2 is going into Ian Fritz 5pulser waveshaper, controlled by another LFO
- The two signals are mixed, and going into the Yusynth ARP4072 VCF (mostly open), and then into a YuSynth VCA.
- Minibrute CV output are going into VCOs, gate into YuSynth ADSR

YuSynth Wavefolder:
Ian Fritz 5pulser:

My DIY synthesizer blog:"

Drums with DIY modular synth

Published on Feb 28, 2014

"I'm using 2 VCAs, 4 LFOs (2 YuSynth VCLFOs), a noise source, and a ringmod, to create rhythmic sounds."

Solfelectro [Solfeggietto by C.P.E. Bach]

Published on Aug 7, 2015 Piano in a Living Room

Thought this was an interesting one. Note the "laser harp" sound comes from the Analog Rytm.

"Solfeggietto in C minor (H 220, Wq. 117: 2) (yeah they used to name music like we name software) composed in 1770 by C.P.E. Bach, son of J.S.

Skinny Pete plays it in the music store scene in Breaking Bad season 5 episode 3 ( [below]

The instrument is a Kawai VPC1 controlling a Clavia Nord Stage 2 using a sampled Clavinet D6, a simulated Farfisa organ, and a few touches of dark virtual analog synth. The beat and "laser" sounds are from an Elektron Rytm controlled via a Yamaha MFC-10 pedal board.

Better sound:"

Skinny pete piano C.P.E. Bach - Solfeggietto Breaking Bad

YMO/pure jam(cover)

Published on Aug 8, 2015 Tosh Ara

"アルバム「テクノデリック」よりpure jamをカバーしてみました。
ミスタッチありますが、どうぞ雰囲気をお楽しみ下さい…(^ ^)ゝ"

DSI Sequential Circuits Prophet-6

Elektron Machinedrum SPS-1 UW+ MKII drum synth/sampler

via this auction


via this auction

"Here is a very rare KORG FK-1 SYNTHPEDAL in 100% functioning condition. I bought it without the original pedal and had a brilliant technician go over it and check everything. He modded a new moog ep-3 pedal to work as the controller for this unit and added a TRS jack to replace the old weird multi-pin connector. The thing sounds phat and amazing with some massive sweeps possible as well as nuanced sounds to dial in. It has the same filter as the old 700 series korg synths. Use this thing in a live rig or in studio with drums, vocals, organs etc. Im sorry to see it go and hope someone enjoys this. Ill pack it extremely carefully and ship it to you like it was my own. Cheers!"

Circuit Bent Yamaha TYU-30 Keyboard by freeform delusion

Published on Aug 8, 2015 freeform delusion

"Circuit Bent Yamaha TYU-30 keyboard

This is a nice little keyboard with only one voice but it has some classic Yamaha drum loops.

Switchable Deep Feedback Control,
Distortion Switch,
Switchable High Feedback Control,
Glitch/Crash/Noise Yellow Button - Creates some very nice drones, loops, noises and glitches"

freeform-delusion on eBay

1986 German MFB 712 / DDC-1.0 Ad


KORG iM1 on Sale

iTunes: KORG iM1 - KORG INC.
Update: other KORG apps are on sale as well.

Another full blown classic digital synth goes on sale for the iPad. The original KORG M1 retailed for US$2166, UK£1499, JP¥248,000 according to wikipedia. iM1 is currently on sale for $19.99. That's twenty bucks the full blown M1 synth engine, all 19 ROM card expansions update: (including the T1 series) via in-app purchase, and more. A crazy side note is all of it fits in only 84.9M of space.

What's interesting is how spoiled we've become with the low cost of iPad apps, myself included. Did you pick up the iM1 for $29.99 when it originally came out? Will you pick it up for $19.99? Share your thoughts in the comments below. No log in required.

What's New in Version 1.0.3
• Added: VoiceOver (where possible)
• Fixed: preset ranking on Darwin gadget now updates properly
• Fixed: the Scale Step value is no longer edited when changing the Scale
• Other minor bugs fixes and improvements

"HOTTEST SALE! KORG music apps are up to 50% off until August 21!

A complete reproduction – and more - of the legendary M1 that defined an era
Mobile Digital Synthesizer for the iPad

Since it went on sale in 1988 the legendary M1 music workstation rapidly achieved record-breaking sales, becoming a mainstay of the music scene from the late 1980s and beyond. The common element of electronic instruments that have left their name in history is that they had a unique sound that was difficult if not impossible to replicate. Sounds such as the “M1 Piano” is instantly recognizable and have appeared on countless hit records over many years, and yet these are sounds that could only be produced by the M1. And that’s what you can now have on your iPad!

● A faithful reproduction of the original M1 Sound
The PCM data provides the library of the original M1. For the hardware, we analyzed the circuit diagram of the original design, and completely replicated it in software down to the last detailed parameters. Engineers with an exhaustive knowledge of the M1 made careful adjustments in order to obtain the sound of the original unit, something that cannot be obtained simply by sampling the original sounds.

● A continued evolution of the M1
Not content with simply reproducing the original, iM1 provides further evolutionary developments. Synth parts now have the Filter Resonance that was requested at the time of the original. The effect parts, originally consisting of only two effects, have been powered-up to 18 effects. The user interface has also been refreshed with additions such as a KAOSS pad. iM1 is the ultimate version of the KORG M1.

● A gigantic library encompassing 3,300 sounds and 34 cards*
In addition to all 19 of the ROM cards originally released for the M1, iM1 also covers the sounds of the M1EX which expanded the internal PCM of the M1, as well as the sounds of the T-series which appeared as an evolution of the M1. There’s also 'BEST OF M1', a selection of 100 great M1 programs. The new 'Smart Sound Browser' makes it quick to find the desired sound. You can also view the sounds ranked by how often they are selected by iM1 users around the world.
*with all the expansion card installed via in-app purchase

Dataline On Overbridge

Published on Aug 8, 2015 MrDataline!/ProjectDataline

Slipping Glimpser

Published on Aug 8, 2015 wellurban

Intellijel Metropolis meets 303

Published on Aug 8, 2015 DJjondent

"I love acid in the morning.

The Metropolis Sequencer is uber cool. Inspired by the Ryk M-185 (a Roland System 100m sequencer)
Each stage has slides and a pulse count in the range 1-8.

The Luna Modular VC 303 bass synth is according to the manufacturer (Somatic Circuits) an exact clone of the TB 303 minus the sequencer.

For more pics & info:"

Curious when the Luna 303 came out. There was one posted here back in 2012.

Analog Four Octatrack Waldorf Blofeld_Dubtechno_JAM12

Published on Aug 8, 2015 CsG

"Live Dubtechno
Miklós Radnóti poem source:"

DDD5 & Acid8

Published on Aug 7, 2015 The Outsider

"Finally got around to doing a mod on one of my DDD-5s. Similar to the TR-505 I modded recently, the mod entails a 20 X 4 matrix that allows patching between points on the voice ROM chips.

The Acid8 guest stars in the video, providing some melodic accompaniment.

Audio recorded in Logic Pro X via Allen & Heath ZED24 mixer.
Video shot on Nikon D5300.
Everything stitched together in iMovie.
DDD5 mods by 136Mods.

Shits & Giggles, folks."
