MATRIXSYNTH: Monday, January 11, 2016

Monday, January 11, 2016

JBK


Published on Jan 11, 2016 RADIOKLOW

"JBK, Portrait of a friend and artist.
This piece of music was composed as a tribute to my friend, Jean-Baptiste Kempf. Visual artist in computer, Jean-Baptiste Kempf creates is own images and films by complex programming. We worked together a few years ago to produce a video composition called = Meditation : [posted here]

This composition was performed on Virus TI by Marc-Henri Arfeux. The video was also created by Marc-Henri Arfeux"

Spectralis 1 Beta Jam



"During a betatest I often create new music. Most bugs occur, if you really work with the synth and if you simply produce some music. I created some basic Spectralis 1 pattern and did some overdub improvisations with the Accelerator above the backing. The Spectralis 1 is equipped with the factory soundset from 2004 only. It still sounds fresh after all these years;-)"

Synthrotek MST MIDI to CV Module


Published on Jan 11, 2016 synthrotek

"This is a quick, rough demo of our new MST MIDI-to-CV Module and some of it's functions. We show how you can send MIDI information from your DAW (in this case, Ableton Live) and use the MIDI to CV convertor of our module to control a Eurorack system. We also demonstrate sending information back the other way to your DAW; for example, using an LFO in your Eurorack setup to send a Square Wave out to the MST MIDI-to-CV module, which can then be used to change the tempo of your DAW. We also show how you can use the MST MIDI-to-CV module on other gear, like the Korg Volca Sample."

Octatrack with Legowelt Samples (recording test)


Published on Jan 11, 2016 Jacques Mongrel

"I apologize for the background noise. I was trying direct recording to camera which seems to have added some noise. All the samples are courtesy of Legowelt who sampled his Roland JD800."

Moog Source funk bass live tweaking


Published on Jan 11, 2016 SynthMania

"One might think that the lack of knobs on the Moog Source could make the synth slower to program. Actually, the extremely high responsiveness of the 'big knob' makes programming in real time just about as fast as one-knob-per-function machines! :-)"

Moog Source and Roland TR-808.

Vintage Roland PianoPlus SN 203685


via this auction

"the sounds are pre-set pianos and harpsicords. but it has an arpeggiator and analog cr style drum machine....and din sync out!"

Everything ARP Symposium at Berklee College Videos


For those that missed the first stream, a new set of streams are now live in this post.

An Evening with Dave Smith at Pyramind | Video Recap


Published on Jan 11, 2016 Pyramind

http://www.davesmithinstruments.com

Part 2 below.

"On November 12th, Pyramind welcomed a true legend to our facility. The one and only Dave Smith, founder of Sequential Circuits and Dave Smith Instruments who is often referred to as the Father of MIDI.

During An Evening with Dave Smith, which you can watch in it’s entirety, you will get to hear what the new Sequential Prophet-6 synth is capable of in the hands of it's creator. The Prophet-6 is Dave Smith’s tribute to the analog polyphonic synth that started it all—the Sequential Prophet-5. But it’s not simply a reissue of a classic. Rather, as Dave puts it, “It’s the result of our effort to build the most awesome-sounding, modern analog poly synth possible.” The Prophet-6 takes the best qualities of the original Prophet-5—true voltage-controlled oscillators, filters, and amplifiers—and adds enhancements such as studio-quality effects, a polyphonic step sequencer, an arpeggiator, and more. The result is pure, unadulterated analog tone with the stability and reliability of a state-of-the-art modern synth.

For more information about Pyramind events head to our blog: http://hubs.ly/H01Pj5Z0

Timestamps:

01:00 - Hardware vs. Soft Synths - real synths cost more than soft synths (hardware competes with FREE)
02:48 - What inspired you to start building equipment?
05:03 - Talks about the way he developed his synth to work, and what didn’t work for other companies
05:58 - Where do you start when designing your instruments?
09:30 - Talks about the Prophet 6 (voltage controlled oscillators)
12:18 - “Slop Control” feature
14:00 - Analog distortion
16:00 - Story about the new name - Sequential
18:20 - Starts demoing the synth (focused on sequencer)
19:24 - Talks about factory presets and why they’re made the way they are
21:10 - Arpeggiator
22:00 - Effects
24:30 - Analog synthesis has passed the test of time
26:18 - People used to just want to emulate real instruments
28:05 - Inspiration behind the Prophet 2000
30:30 - Why didn’t they quantize oscillator frequencies?
31:40 - Why he likes constrained designs
34:08 - You can know nothing about synthesis and still make cool sounds with these synths
34:58 - USB integration (it’s just midi over USB)
35:20 - Presets
35:48 - Analog gear market
37:30 - Appealing to different clients / genres
38:28 - Taylor Swift Custom Prophet 12
41:14 - What did the sound designers bring to the synth?
42:16 - Hearing presets being used / modified"

An Evening with Dave Smith | Video Recap | Part II | feat. Jason Linder

Published on Jan 11, 2016

"On November 12th, Pyramind welcomed a true legend to our facility. The one and only Dave Smith, founder of Sequential Circuits and Dave Smith Instruments who is often referred to as the Father of MIDI.

During An Evening with Dave Smith, which you can watch in it’s entirety, you will get to hear what the new Sequential Prophet-6 synth is capable of in the hands of it's creator. The Prophet-6 is Dave Smith’s tribute to the analog polyphonic synth that started it all—the Sequential Prophet-5. But it’s not simply a reissue of a classic. Rather, as Dave puts it, “It’s the result of our effort to build the most awesome-sounding, modern analog poly synth possible.” The Prophet-6 takes the best qualities of the original Prophet-5—true voltage-controlled oscillators, filters, and amplifiers—and adds enhancements such as studio-quality effects, a polyphonic step sequencer, an arpeggiator, and more. The result is pure, unadulterated analog tone with the stability and reliability of a state-of-the-art modern synth.

For more information about Pyramind events head to our blog: http://hubs.ly/H01Pj5Z0

Timestamps:

00:46 - How do you know when the synth is “done”?
01:32 - Prophet 6 circuit board vs. Prophet 5
02:00 - Prophet 6 poly chaining, module version
03:08 - Tempest design vs Prophet 6
06:05 - Problems with having too much input during design stage
07:10 - Any high profile sound designers?
07:50 - Demoing
09:20 - Spring reverb model (hitting the side of synth)
12:26 - What was the hardest feature to cut during design?
13:30 - Favorite synth he has made
14:10 - Talks about polymod (one of the most unique things about the Prophet 5) individual modulation PER VOICE
16:00 - Jason Lindner (Keyboardist of Now vs. Now) demo
22:58 - Compares choosing synths to the way guitar platers choose guitars
24:17 - When do you think about what to build NEXT?
25:48 - Will you ever make guitar pedals or effects?
26:50 - Are you continuing to build your back catalog?
28:25 - Is there an audio input? (No)
29:41 - Filter poles (4 pole for lowpass, 2 pole for highpass)
30:24 - Unison mode demo (chord hold)
33:08 - Analog gear cost
35:10 - What do your employees do?
37:55 - Talked about doing a hybrid analog digital vocoder
39:50 - How are the synths assembled?
41:18 - What changed after having employees?
43:39 - Are you less connected with your products now that you have employees?"

You'll find some event pics on Pyraminds website here.

NAMM: New Yamaha Montage AWM2 & FM-X Synthesizers

Update: cleaned this post up a little (note below).

Another one in via Soviet Space Child via this site. Scan via sequencer.de.

"Yamaha Montage Synth, Based On Entirely New Technology

YAMAHA’S NEW MONTAGE synth offers unprecedented ways for keyboard players to control and interact with sound.

For more than 40 years, Yamaha has developed industry-leading synthesiz-ers, from the revolutionary DX7 in the 1980s to the renowned Motif series, one of the best-selling synthesizers of all time. The Montage, available in 61-, 76-, and 88-key configurations, features the Motion Control Synthesizer Engine, a powerful and intuitive way to interact with and control sound.

The Motion Control Synthesizer Engine controls two iconic Sound Engines: Advanced Wave Memory 2 (AWM2) and FM-X. Compatible with previous generation Motif libraries, the AWM2 engine is exponentially more powerful than the previous Motif XF flagship with nearly ten times more wave memory, integrated flash, double the effects, and twice the polyphony. Joining the powerful AWM2 engine is FM-X. A sophisticated pure FM (Frequency Modulation) synthesizer engine is capable of producing classic ‘80s or cutting-edge EDM sound with excellent dynamic range, power, and fidelity.

Montage also features a brand new user interface with color touch screen, endless rotary encoders and the Super Knob: a macro control allowing users to control multiple parameters simultane-ously.

‘Montage is the culmination of over forty years of synthesizer legacy and innovation,’ said Nate Tschetter, mar-keting manager, music production, Yamaha Corporation of America. ‘Playing and experiencing Montage is, quite simply, inspiring.’

Anaheim Marriott Marquis Ballroom http://4wrd.it/Montage

Yamaha’s Montage con-tains two discrete sound engines for expanded tonal flexibility."



Update: A quick note on the evolution of this post. As typically happens, stuff gets sent in, I parse it, post it, and then updates come in. Below is the original blob of text I was confronted with from the source site. This was before the scans went up. It appears the source site did a bad copy and paste of the article and jumbled sections out of order. Imagine reading it first. Some of you did and got to enjoy my experience. For those that didn't here you go. A Tacky what?

"NEW PRODUCTS Yamaha Montage Synth, Based On Entirely New Technology user interface with color touch screen, endless rotary encoders and the Super Knob: a macro control allowing users to control multiple parameters simultane-ously. “Montage is the culmination of over forty years of synthesizer legacy and innovation,” said Nate Tschetter, mar-keting manager, music production, Yamaha Corporation of America. “Playing and experiencing Montage is, quite simply, inspiring.” Anaheim Marriott Marquis Ballroom http://4wrd.it/Montage Yamaha’s Montage con-tains two discrete sound engines for expanded tonal flexibility. VATER TACKY SACK VATER PERCUSSION’S new Tacky Sack Grip Enhancer, the first product of its kind to be marketed to the drumming world, features a sack of grip-enhancing rosin powder that absorbs moisture and provides drummers additional control of their drumsticks while performing in humid and sweaty conditions. Gently “clapping” hands on the Tacky Sack applies rosin powder to the palms. A cord is included to hang Tacky Sack from a snare drum, stick bag, or hard-ware. “Once again, Vater knows just what I need, even before I do,” said Slipknot’s Jay Weinberg. “Especially in intense, sweaty environments, Tacky Sack allows me to lose myself in the vibe of a song without worrying if I’m going to send a stick flying from my palms. My grip relaxes, and I’m better able to avoid carpal tunnel-like problems. Tacky Sack lets me thrash with com-plete control.” Marilyn Manson’s Gil Sharone added, GRIP ENHANCER YAMAHA’S NEW MONTAGE synth offers unprecedented ways for keyboard players to control and interact with sound. For more than 40 years, Yamaha has developed industry-leading synthesiz-ers, from the revolutionary DX7 in the 1980s to the renowned Motif series, one of the best-selling synthesizers of all time. The Montage, available in 61-, 76-, and 88-key configurations, features the Motion Control Synthesizer Engine, a powerful and intuitive way to interact with and control sound. The Motion Control Synthesizer Engine controls two iconic Sound Engines: Advanced Wave Memory 2 (AWM2) and FM-X. Compatible with previous generation Motif libraries, the AWM2 engine is exponentially more powerful than the previous Motif XF flagship with nearly ten times more wave memory, integrated flash, double the effects, and twice the polyphony. Joining the powerful AWM2 engine is FM-X. A sophisticated pure FM (Frequency Modulation) synthesizer engine is capable of producing classic ‘80s or cutting-edge EDM sound with excellent dynamic range, power, and fidelity. Montage also features a brand new Vater Tacky Sack Grip Enhancer. 224 MUSIC TRADES February 2016"

Update: and a slightly longer one on YouTube sent my way via Soviet Space Child:


MONTAGE is coming soon Published on Jan 15, 2016 yamahacorporation

"Yamaha flagship Synthesizer MONTAGE is coming soon"

And some pics via Soviet Space Child:


New KORG Minilogue Flyer & Price


You'll find them here, in via Soviet Space Child.

New Electro-Harmonix Super Space Drum and Crash Pad


Published on Jan 11, 2016 EHX

"EHX’s rich history was marked by many revolutionary pedals but one of our most distinctive lines was a group of analog drum synthesizers that included the Crash Pad and Super Space Drum.

Like the original from 1980, the new Crash Pad can create an array of drum sounds and other-worldly oscillation sweeps, as well as process external sounds thru its resonant filter. Plus, it’s been updated to respond to expression pedal/CV input for external control over the filter in real-time.

A faithful reissue of the cult-classic released in 1979, the Super Space Drum uses analog synthesis techniques to create mind-blowing sounds ranging from deep kicks to high toms to sci-fi drums. Trigger it from the built-in pushbutton or an external (non-MIDI) electronic drum pad. Pass external sounds through the gated amplifier via the aux input. The Super Space Drum lets you create, control and manipulate a stunning array of synthesized sounds."

LushOne Mini Modular Hybrid Digital Analog Synth




via this auction

"A nice little mini modular with a good selection of features -
2 DCOs each with 5 waveforms and a CV input. One useable as an LFO
2 ADSRs
1 LPF with 1 input and 2 CV inputs
2 Square+Triangle LFOs
1 Gateable square LFO
2 VCAs
2 Ring Mods
4 RCA Breakouts and 1 MiniJack breakout
1 Joystick controller with button out
1 noise source
1 sample and hold
4 imput signal mixer
Midi in

I think that's about it...

It's quite a fun piece of kit - good fun to use with a eurorack modular, or just freerunning on its own.
Here's a quick play around from today with it patched to itself doing some some fake stereo panning using the two VCAs and LFOs. The only external effect was a little bit of reverb [embedded above] - For some reason the ADSR knobs work in reverse - no idea why. But it's like that on both for some reason.

Powered by a 12v wall-wart type power supply which I'm including, and about 30 mini-banana patch cables and all topped off with a bunch of 1900 type knobs.."

KQ MiniSynth Polyphonic Modular Synthesizer for iOS


iTunes: KQ MiniSynth - Ryouta Kira

"KQ MiniSynth is a polyphonic modular synthesizer.

The maximum number of modules you can set is 100!
..Of course it depends on your device's ability.
You can install 10 Oscillators, make 10 series FM Modulators, and so on as you want.

External MIDI (e.g. iRig MIDI) is Supported.
Inter-App Audio is Supported.

This app implements the follow modules.

Oscillator
- Oscillator Type A (Frequency Modulation)
- Oscillator Type B (Pulse Width Modulation)
- Super Saw Oscillator
- Low Frequency Oscillator
- White Noise Generator

Mixer/Amplifier
- 4 Channel Mixer
- Voltage-Controlled Amplifier
- Sample-and-Hold Amplifier
- Booster

Envelope/Logic
- Envelope Generator Type A
- Envelope Generator Type B
- Inverting Circuit
- Logical And (Series Switch)
- Logical Or (Parallel Switch)
- Maximum/Minimum Selector

Modulator
- V/Oct Vibrator
- Keyboard Level Scaling
- Ring Modulator

Filter/Effector
- Voltage-Controlled Filter (LPF/HPF/BPF/BEF)
- Delay Effector
- Reverb Filter
- Compressor

The app was tested on iPod touch 4G, iPhone 5s, iPad 2, and iPad mini 3.
The Recommended Minimum Device: iPhone 5, iPad 2, or newer.

If you feel noisy or slow, try to decrease polyphony and increase buffer size on Settings.app."

Vactrol - More work in progress


Published on Jan 11, 2016 cephal0p0d

"Bitey bass is Pulse2
Most sequencing on BSP
Control and some sounds with ESQ
Drums are Tama 305
Bips from Frac
Modulated reverb from REV500
Recorded on an iPhone, so suck it up."

PULSAR - Overview [Reaktion]


Published on Jan 11, 2016 Reaktion Soundtools

"Quick overview of our new release for Reaktor: Pulsar.

Read more and buy it at: http://www.reaktion-sound.com/"

Synthesizer Meets Guitar - Patch of The Week


Published on Jan 11, 2016 Doug Lynner

"A performance patch for Serge Guitar.

To see the modules used in this Patch of The Week in detail see the Mystery Serge at http://www.serge.synth.net/gallery/dl....

Doug offers modular synthesizer lessons and consultations. For information write doug@neatnetnoise.com.

Doug's website is http://www.neatnetnoise.com."

David Bowie Tribute - Space Oddity by Jordan Rudess


A beautiful tribute by Jordan Rudess was just added to the bottom of the main post here.

RIP David Bowie


Published on Mar 6, 2014 Halloweenjack84

Good advice for life as well. David Bowie lived it, and gave many of us the freedom to live it right alongside him. He is a hero in the truest sense. One of the most famous, yet kindest human beings on earth. His influence is quite literally beyond measure. It isn't just his music. More than anything it is permission to be whoever the hell you want to be and the permission to tell anyone who judges you to f off, all the while being kind about it. No apologies, no time wasted. Think about that a bit. He will continue to give freedom to countless generations to come, simply by being the person he was. I love his music, I cherish what he gave us, and I love how he did it - he made it cool to be yourself while at the same time being kind, tolerant, and compassionate towards others. He was the best of the best, and I love him for that.

Thank you captain. If there is existence after death, I hope you are enjoying it as much as we enjoyed your existence here with us.

---

On the synth side of things, because this is a synth site after all, I was curious how many posts mention David Bowie. I knew there would be a few. It turns out there wasn't just a few, but a whopping 77 posts total. That from a man not known for synths. Many of the posts are repeat references to Bowie's use of the stylophone and other synths, but there are some true gems there. Spend some time looking back on his influence on the synth world. He touched everyone. The following is just a handful of tributes from the synth community. If you have any to add, please feel free to leave a comment below.



via @dsisequential

"Thank you David Bowie, your music will live on forever."


via @moogmusicinc

"Thank you Starman, for inspiring us to trust our curiosity.

RIP David Bowie [1947-2016]"


via @Moogfest

"So long sweet star man. #davidbowie #stylophone"


via @ctrl_mod

"RIP, Maestro."


via @makenoisemusic, via @FACTMag

"No one else made a mug shot look this good."



via @SE_BoomStar aka Studio Electronics

"Riposa in pace Musicman of Earth. #Bowie"


via @malekkoheavy

"Just for one day https://www.instagram.com/p/BAZ9U7xSIQn/"


via Brian Eno, via @dsisynth, via @brandonstosuy


David Bowie - Warszawa Published on Aug 23, 2014

Synth heavy track "From 'Low' (1977)" via @Synth_City

"Warszawa" for Mellotron and Minimoog

Uploaded on Feb 22, 2010

"Educational.

An excerpt from David Bowie's 'Warszawa'. Played on my Wakeman combo."


And the song that started it all for me, Ashes to Ashes, followed by his final two.

David Bowie - Ashes To Ashes

Published on Mar 6, 2009 emimusic

David Bowie - Blackstar


David Bowie - Lazarus

Published on Jan 7, 2016 DavidBowieVEVO

"He always did what he wanted to do. And he wanted to do it his way and he wanted to do it the best way. His death was no different from his life - a work of Art. He made Blackstar for us, his parting gift. I knew for a year this was the way it would be. I wasn't, however, prepared for it. He was an extraordinary man, full of love and life. He will always be with us. For now, it is appropriate to cry." - Tony Visconti (1/11/2016)

Allen Strange Buchla Dream Machine


Published on Jan 11, 2016 Todd Barton

"This is an attempt at Allen Strange's figure 6.72: Dream Machine patch from his book
Electronic Music: Systems, Techniques & Controls. You can find the patch diagram with my Buchla module notations here:
https://www.hightail.com/download/ZWJ...
and a better audio of this here:
http://soundcloud.com/user7621213/all..."

Super Clean Roland SH-101 with Mod Grip


via this auction

Live Studio Jam 006 , 1/11/16 . Korg Volca and Arturia !!


Published on Jan 11, 2016 Todd Smith

": Gear Used :

Korg MicroKorg
Korg Volca Bass
Korg Volca Keys
Korg Volca Beats
Korg Monotron Delay
Arturia Microrbute
Midi Solutions Quarda Thru
Behringer Micromix MX400
Tascam US-144mkII Audio Interface
Waves Supertap & MetaFlanger
Ableton Live 8

: Setup :

The Korg Volca Bass , Korg Volca Beats , Korg Volca Keys and Mico Brute are all on sequence duty . The Micro Korg and Korg Monotron Delay are played live . I hope you enjoy this set . Take care !!"

New Vermona twinCussion Eurorack Module Front Panel


A drawing of the latest twinCussion prototype module from Vermona that will be shown at NAMM this year.

The twinCussion was actually shown back at NAMM 2015. You'll find a video previously posted here.

A New Look for Audio Damage's Sequencer 1 by Ninstrument


via Ninstrument

"This is one of the best Sequencers in euro today. I really love the repeats and ratchets, but I sometimes screw up the timing when pressing the buttons manually to activate them. I decided to add the feature to the hardware and also give it a new look in black face. Almost looks a little Elektron like don’t you think? If you are interested in finding out more info on this sequencer, please check out the manufacturer’s product page here."

MALEKKO - VARIGATE 4 w/Josh Holley and Paul Barker


Published on Jan 11, 2016 Malekko HeavyIndustry

"Josh Holley and Paul Barker employ the new Malekko Varigate 4 in the studio.

note: units ship with red LED's unlike the unit you see here (of course Josh had to have pink).

for more info on this 4-channel 8-step gate sequencer: https://malekkoheavyindustry.com/prod..."

Audulus Patch - Rising Edge DS2AS Synth


Published on Jan 11, 2016

"To download for free, go to: http://forum.audulus.com/discussion/8...

www.biminiroadelectronics.com/audulus"

iTunes: Audulus 3 - Audulus LLC

Roland TR-808 driving Synthesizers.com Q119


Published on Jan 10, 2016 SynthMania

"Roland TR-808 driving Synthesizers.com Q119"

Andrew Hunter - Eurorack Modular Synthesizer Improvisation #6. Jan, 11 2016


Published on Jan 11, 2016 Andrew Hunter Music

"Bassline: metropolis + analogue oscillators + wasp filter. Lead: E340 cloud generator + pittsburgh delay + springray. Metallic percussion: Pittsburgh DNA + Boogie filter. Drums: tiptop + 4ms clocks +ustep."

Orgone Accumulator by Scrotum Lab - Drum mode demo


Published on Jan 11, 2016 batchas

"Orgone Accumulator adapted for the BugBrand Modular System by Scrotum Lab.
The circuit is the original from Neutron Sound.

In this video, the Orgone is set in DRUM mode. Showing here some sound examples.

Here is the same version with additional effects:"

Orgone Accumulator by Scrotum Lab

Published on Jan 11, 2016

"Orgone Accumulator adapted for the BugBrand Modular System by Scrotum Lab.

The circuit is the original from Neutron Sound.

In this video, the Orgone is set in DRUM mode."

Roland JP 08 Presets & Step Sequencer


Published on Jan 11, 2016 muzykujkropkacom

Roland JP 08 Step Sequencer

Roland JU 06 Presets & Step Sequencer


Published on Jan 11, 2016 muzykujkropkacom

Roland Ju 06 step seq

Roland Boutique Series Sequencers-synchronized


Published on Jan 11, 2016 ED電音頻道 E.D.Music Channel

"©E.D.Music Co.
Gears used: Roland JP-08, JX-03, JU-06
Special thanks: Tom Lee Music"

Roland Boutique Series LFO-Patched Comparison


Published on Jan 11, 2016 ED電音頻道 E.D.Music Channel

"©E.D.Music Co.
Gears used: Roland JP-08, JX-03, JU-06
Special thanks: Tom Lee Music"

Roland Boutique JU-06,JP-08 midi controlled with Ipad


Published on Jan 10, 2016 Creamtronic

"Hello,
just a little demonstration to controll the Roland Boutique (Ju-06,JP08) synthesizer over midi/Sysex with Ipad and the app 'TB midi stuff'
Every fader movement or button pushing can be recorded in your DAW. It works very fine.
The JU-06 template for the app you can download here:
http://www.mediafire.com/download/1ut...

Special thanks to "IraVirus" who made the JP-08 Template, you can find him and his work in the roland/clan forum.
http://forums.rolandclan.com/viewtopi...

The sounds are nothing special just to demonstrate the functionality
JU-06 : Preset with the Sequencer
JP-08 : Preset and i recorded (midi) a chord in my Daw and looped it.
The app Tb midi stuff is not a expensive one and i can really recommend it.
It is possible with the software to convert the sysex in midi cc 'IraVirus' has realise that in his JP-08 template.
I hope that would help some people who are interested in this kind of stuff ;)
Best regards, Creamtronic"

via discchord

Update:

Roland Boutique Midi CC to Sysex with Ipad

KATOD - 7CATS - Pussy


Published on May 1, 2015 KATOD_music

"Electronic / instrumental music

instruments:
- moog synth
- modified C64 + synth software
- bass guitar
- electric solo guitar

Composed, recorded, mixed and mastered by KATOD
Video-clip recorded and assembled by Katod."

via CatSynth

Rare Fonitronik Analog EFM 1900 and 3500 Modular Synthesizer Modules, Kits, and Parts


via this auction

"Manufacturers of similar modern modular synthesizers include Buchla Electronic Musical Instruments, Doepfer Musikelektronik, Macbeth, Moog Music, Synthesis Technology, PAiA Electronics, Pittsburgh Modular, Analogue Systems, and Synton.

This lot of complete modules and parts are from the EFM series 1900 and 3500 series synthesizers from Tom Gambles Electronics For Music. Nearly everything you need to build a beastly analog modular synthesizer!

Full lot contains the following:

Complete Modules
4 x 3541 VCO
1 x 5x3 multiplier
1 x DEG2A dual ADSR
1 x RX-CV Midi to CV gate
1 x EGLFO1A ADSR/LFO
1 x VCO4E Moog Rogue
1 x VCA5B hybrid VCA/mixer
1 x VCF1E Oberheim 2pole HP/BP/LP filter
1 x PSU 12V power supply

PCB’s only
2 x 3506 – LAG slide/glide/pitch bend
1 x 3541 - VCO
3 x 3508 – ADSR
2 x 1605 – VCF6C EMS diode ladder
1 x 4303 – LFO5A vc lfo/s&h/noise
1 x 1003 – RMP1B ring mod/lfo/preamp

Components
5 x PT146 precision resistors
50 x MF1/4DL3303F Metal Film Resistors - Through Hole 330K
4 x 064W503 Trimmer Resistors - Through Hole 50K 10% 3/8"MULTITURN
100 x 1N4148 Diodes - General Purpose, Power, Switching 100V Io/200mA BULK
25 x CHB471k1H821 ceramic capacitors
25 x C1C101J1H551 ceramic capacitors
100 x 3319P-2-503 Trimmer Resistors - Through Hole 9MM RND 50KOHMS 25% 0.2WATTS

Integrated Circuits
20 x NJM072BD Operational Amplifiers - Op Amps Dual
16 x NJM13600D Transconductance Amplifiers Dual
10 x CD4001UBE Logic Gates CMOS Quad 2-In
5 x NTE912
10 x NJU4066BD Analog Switch ICs CMOS Quad
20 x LM393N Analog Comparators 2-36V Dual
3 x NE555N Timers
90 x 8 IC socket
30 x 14 IC socket
25 x 16 IC socket

As well as miscellaneous LEDs, ~100 knobs, ~40 Al faceplates, resistors, capacitors, diodes, and trim potentiometers.

Sound Samples
bntic.mp3
PS3100_02_15V.mp3
modular6_07.mp3
SL01.mp3

The Plan....The whole point was to design a series of small boards that could be used as building blocks as well as individual modules. They can be mounted on a panel or put on a motherboard and used a single board modular. Most of the boards are designed with the i/o connectors all on one side of the board. Using 90 degree headers they can even be mounted vertically.

More information about the modules, diagrams, and mods can be found here"

Yamaha CS30 SN 1217


via this auction

Yamaha CS-15D Synthesizer Keyboard w/ HARD CASE


via this auction

Roland Jupiter 6


via this auction

Vintage Sequential Circuits Prophet 600 Analog Synthesizer SN 5040


via this auction

Bugbrand Modular - Orgone Accumulator


Published on Jan 11, 2016 batchas

"Orgone Accumulator adapted for the BugBrand Modular System by Scrotum Lab.

The circuit is the original from Neutron Sound."

Roland SH-101 Restoration - Bubble Bath and Dead Key Fix


Published on Jan 11, 2016 GOLT !

"A full tear down and clean of the SH-101. Includes how to fix a common dead key issue and explains the 8 x 4 keybed matrix."

24² avant dans la nuit


Published on Jan 11, 2016 Ebotronix

"two 24 step sequences by 2x Pressure Points/Brains, RCD,A152
& Roland System 104 Sequencer
+ ~ -

Erica Synths - Dual EG / LFO


Published on Jan 11, 2016 DivKidVideo

"First thing to note that I didn't mention in the video is that the module does save it's setting while powering down so you can fire up the case and everything be just as you left it.

It's a fun unit with dual ADSR, dual AD and two LFO modes offering a looping AD or Rise, Hold, Fall LFO. You can combine any of those across the two channels for powerful little modulation device."

ARPIE Midi Arpeggiator + Sequential Circuits Pro One


Published on Jan 11, 2016 midierror

"A short video recording the synth direct, no effects.

Via an Arturia Minibrute for MIDI to CV"

JD XiSound0111


Published on Jan 10, 2016 ryouichi harada
PREVIOUS PAGE NEXT PAGE HOME




©2019 Matrixsynth - All posts are presented here for informative, historical and educative purposes as applicable within fair use.
MATRIXSYNTH is supported by affiliate links that use cookies to track clickthroughs and sales. See the privacy policy for details.
MATRIXSYNTH - EVERYTHING SYNTH
